Installation requirements
Installation angle:As shown in the figure. The angle between the card reader and the pole is about 30 degrees, and the front of the card reader is tilted by about 30 degrees toward the road surface where the car enters.
Specifications
| Operating Voltage | DC 12-24V/2A |
| Working current | <500mA |
| Operating temperature | -20~+60°C |
| Working humidity | 5%~90% |
| Waterproof and dustproof grade | IP65 |
| Receive sensitivity | -110dbm |
| Serial communication baud rate | 9600bps,N,8,1 |
| Communication Interface | RS485,Wiegand26/Wiegand34,RS232(optional) |
| working frequency | 433MHz |
| Recognition speed | 60km/h(max) |
| Card reading interval | 1s-15s (Adjustable) |
| Card reading distance | 1-15m |
| Recognition angle | <60° |
| Modulation | ASK |
| Output | 1 relay output interface |
| Input | 1 input trigger interface |
| Device address | 1-15 |
| Installation method | Vertical installation |
| Size | 260*210*59mm |
| weight | 2KG |
Advantages
1. Technical Solution Innovation
The other brand Bluetooth card on the market usually has a battery life about 6 months, and some better one can be used for about 12 months.
But the Bluetooth card produced by JUTAI, the entire design concept is completely from the perspective of low power consumption.
With conventional Bluetooth cards, our battery life can be used longer than one and a half years. The ultra-low power consumption card designed by JUTAI can have a super long battery using life,which can be used at least 2.5 years. (Battery model CR2032, brand: Panasonic, one card with 2 Battery as standard);
2. JUTAI Card Very Hard To Copy
The other brand Bluetooth card on the market has low chip cost and low encryption level.
JUTAI Bluetooth card adopts a high-level encryption technology, so JUTAI Blue Cards is more difficult to copy ,so our blue cards can improves the security level of the entire community. And In addition, property companies can easily make a profit.
3. Comprehensive cost-effective
After many years of technological precipitation and accumulation,JUTAI have very rich experience in the radio frequency field. We do R & D and production of all series of stable and reliable long-distance rfid reader. And sell to foreign country Wholesalers or projects intergrator directly, so we can have an absolute advantage in cost.
