Specification
| Working voltage | DC12V-24V |
| Working current | less than 300mA |
| Working Temperature | -40℃ to +75℃ |
| Relay Signal | 4-ways,NO/NC signal can be jumper, default NO) |
| Trigger Signal | 1 circuit (trigger when the signal is grounded) |
| Weigand output signal | 1 group |
| Add/delete ID | each group of signals |
| ID capacity |
255
|
| RF frequency | 433Mhz |
| RF remote distance | 25m/100m |
| Size | 175*120*60mm |
