Technology Parameter
| Power Supply | <=100MA |
| Baud Rate | 9600,n,8 |
| Trigger Frequency | 125k |
| Communicate Frequency | 2.45G |
| Relative Humidity | <=90% |
| Read Distance | 0-2.6m in air (JUTAI battery smart card ID-52) |
| Receiving Sensitivity | -90dBm |
| Anti-Collision Capacity | 100pcs |
| Integration Frequency | 13.56mhz(2-3cm Reading Distance) |
High Security of resisting disturbance
Adopts frequency hopping&multi-type address technology,strong encryption to the card info by the unique program encryption technology,data transmitting to reader after multi-type checking way for data processing.
Strong Anti-Collision Capacity
100PCS card ID can be read simultaneously wihin3s.This function most suit for hands free lift/elevator control system
Reading distance can be controlled exactly
Reader be waked up by 125K low frequency activator,and which can control the reading range effectively. And the reading distance can be setting from 1-2.6m, max distance is 2.6m.
Multi-type Data output format
Semi-passive mid range reader With wiegand 26 /Wiegand 34 data format for selection,and which can easy to integrate into any access control system.
