Introduction
With a high-performance 32-bit ARM Cortex-M3 core microcontroller，Tag identification speed: 50 tags/sec (sending by time)，Tag reading capacity: 50 tags/sec，High security of resisting disturbance，Adopts frequency Hopping& multi-type address technology, Strong encryption to card info by the unique program encryption technology, data transmitting to the reader after multi-type checking way for data processing.
Function
With 18dBi high-gain directional antenna, Directional Capacity: 30:1，With a signal attenuator, the reading distance can be adjusted from 1 to 30 meters, which can solve customers` s different requirements in a real application，Maximum Reading Distance can reach 30 meters, it is the best solution for long-range parking identification system applications.
| Power Supply | 32-Bit Arm Cortex-M3 |
| Reader Capacity | 50tags/Sec |
| Buffer Capacity | 50tags(Anti-Reread) |
| 50tags(Anti-Reread) | -20ºC~+85ºC |
| Attenuation Distance | 1 to 30 Meters Adjustable |
Note: it can receive RFID tag info directly, no need waked up RFID tag.
